Motor dobro do FCU do condicionamento de ar do eixo
Double Shaft Air Conditioning FCU Motor Motor Application: Fan coil motor is used in various fan coil unit, including indoor fan coil unit of central air conditioner, kinds of high static pressure air conditioner fan coil, axial and cross flow fan. Technical Parameters: Note: Listed are representative motors, only for reference, dimensions can be customized according to customer requirements. OEM/ODM can be offered. Model Number Voltage /V Frequency /Hz Power /W Current /A
-
Único motor da unidade da bobina do fã do eixo
16W 4 pole three speed asynchronous fan coil motor used in commercial air curtain machine Motor Application: Fan coil Indoor unit of ceil aircon Central aircon EVEs Commercial air curtain machine Sterilization equipments Technical Parameters: Model Number Voltage /V Frequency /Hz Power /W Current /A Speed /RPM Capacitance /uF YDK110-8-6 220-240 50/60 8 0.12 700/560/450 1.2 YDK110-10-4 220-240 50/60 10 0.15 750/600/480 1.2 YDK110-16-4 220-240 50/60 16 0.17 800/640/510 1.5
-
Motor para Unidade Fan Coil de 48 Quadros - 1/6HP 230V 50/60HZ 1330RPM/3SPD
-
Motor de unidade de bobina de ventilador de 48 quadros - 1/4HP 230V 50/60HZ 1330RPM/3SPD
-
Vídeo
Motor de bobina de ventilador de 48 quadros - 1/5HP 230V 50/60HZ 1300RPM/3SPD
-
Vídeo
Motor para ventilador de bobina de 42 quadros - 90W 220-240V 50HZ 1330RPM/4VEL
-
Vídeo
42 Motor de bobina de ventilador de quadro - 120W 220-240V 50/60HZ 1300RPM/3SPD
-
Vídeo
Motor para Fan Coil 48 Frame - 185W 1/4HP 230V 50/60HZ 1300RPM/3SPD
-
FCU Motor personalizado - 90W 240V 60HZ 1000RPM/3SPD
5-Step Selection Methodology Step 1: Match Electrical Specifications (The Non-Negotiables) First, locate the nameplate on your existing motor. This is your most important source of truth. You must verify: Voltage & Phase: Common voltages are 115V or 230V, single-phase. Warning: Operating a motor on incorrect voltage will cause it to burn out. Horsepower (HP) or Wattage: The replacement motor must have an equal or slightly higher rating. Use conversion: 1 HP ≈ 746 Watts. RPM
